Paper Material Flexo Printing Machine with Advanced UV IR Dryer and Hot Air Drying

FM-B650-B1320 Flexographic Printing Machine



Application Object
Suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.

Paper Used
Kraft paper, paperboard, coated paper, liner paper, laminated paper, multilayer composite paper, carton board materials ect.


Technical Parameters:

Specification	650	920	1020	1220	1320
Max. Web Width	650mm	920mm	1020mm	1220mm	1320mm
Max. Printing Width	600mm	900mm	1000mm	1200mm	1270mm
Printing Repeat	286-1200mm	286-1200mm	286-1200mm	286-1200mm	286-1200mm
Max.Unwinder Diameter	1524mm	1524mm	1524mm	1524mm	1524mm
Max.Rewinder Diameter	1524mm	1524mm	1524mm	1524mm	1524mm
Gearing	1/8cp	1/8cp	1/8cp	1/8cp	1/8cp
Max Printing Speed	150m/min	150m/min	150m/min	150m/min	150m/min
Diameter of web roller	100mm	100mm	100mm	100mm	100mm
Drying mode	Hot Air Drying/IR Drying/ UV Drying (Optional)
Oil used	Water based ink/ UV ink
Power Requirement	380V 3PH 50Hz
Substrate	17gsm copy paper, cotton paper, 60-400g art paper, aluminum-foil paper, paper board, kraft paper

       Wenzhou Fengming Machinery Co,Ltd was founded in 2006,is a pro­ fessional manufacturer of all kinds of packaging printing machinery.The com­ pany has always been in line with the" quality foundry Fengming brand" and "pursuit of excellence" corporate philosophy.committedto the development and development of new products,formed a design,research and develop­ ment,prodution,sales as one of the operational system.
      The company mainly produces internationally advanced,domestic leading level of computer color flexographic printing machine,unit type wide flexog­ raphic presses and other printing and packaging machinery products,for domestic and foreign customers to provide quality products and satisfactory after-sales service.In recent years,our company adhering to the concept of green environmental protection,the development of non-plastic environmen­ tally friendly machinery products,by the domestic and foreign markets.
