Non Woven Bag Printing Machine for Max. Printing Width 900mm and 60-350GSM Paper Roll

FM-B650-1320 MODEL FLEXOGRAPHIC PRINTING MACHINE




Application Object
Suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.

Paper Used
Kraft paper, paperboard, coated paper, liner paper, laminated paper, multilayer composite paper, carton board materials ect.

Technical Parameters:

Specification	1020	1300	1350
Max. Web Width	1020mm	1300mm	1350mm
Max. Printing Width	1000mm	1270mm	1320mm
Printing Repeat	286-1200mm	286-1200mm	286-1200mm
Max.Unwinder Diameter	1524mm	1524mm	1524mm
Max.Rewinder Diameter	1524mm	1524mm	1524mm
Gearing	1/8cp	1/8cp	1/8cp
Max Printing Speed	150m/min	150m/min	150m/min
Diameter of web roller	100mm	100mm	100mm
Drying mode	Hot air Drying/IR Drying/ UV Drying
Substrate	80-400g chrome paper, aluminum-foil paper, BOPP, paper board, kraft paper.

       Wenzhou Fengming Machinery Co,Ltd was founded in 2006,is a pro­ fessional manufacturer of all kinds of packaging printing machinery.The com­ pany has always been in line with the" quality foundry Fengming brand" and "pursuit of excellence" corporate philosophy.committedto the development and development of new products,formed a design,research and develop­ ment,prodution,sales as one of the operational system.
      The company mainly produces internationally advanced,domestic leading level of computer color flexographic printing machine,unit type wide flexog­ raphic presses and other printing and packaging machinery products,for domestic and foreign customers to provide quality products and satisfactory after-sales service.In recent years,our company adhering to the concept of green environmental protection,the development of non-plastic environmen­ tally friendly machinery products,by the domestic and foreign markets.
